22.5×11.75 TUBELESS 22115001A
PART NO.:22115001A
Tubeless wheels for trucks, buses, semi-trailers, trailers.
This 22.5×11.75 tubeless truck wheel is engineered with an 8mm rim thickness and 16mm disc thickness, offering the highest durability in the series. Weighing 50kg, it supports a maximum load of 5500kg, ideal for trucks facing extreme payload demands.
APPLICABLE ROAD
ON-HIGHWAY
RIM SIZE
22.5×11.75
RIM THICKNESS
8
DISC THICKNESS
16
HAND HOLE TYPE
ROUND
HAND HOLE NO.
10
STUD HOLE NO.
10
STUD HOLE DIA.
φ26
STUD HOLE TYPE
ROUND
P. C.D
φ335
C.B.D
φ281
OFFSET
0/120
MAX LOAD
5500
WEIGHT (KG)
50
Подробности о продукте
5500-6000KG Load Capacity | Reinforced for Long-Haul & Heavy Transport
Ultra-Strong, Lightweight Design for Maximum Efficiency
22.5×11.75 tubeless steel wheel with reinforced wheel disc/rim structure– supports 5,500-6,000 kg loads
Advanced alloy steel construction – 15% lighter than standard wheels, 30% stronger
Optimized for 385/65R22.5 tires (low rolling resistance)
✔ Highway-optimized – reduces fuel consumption by 2-3% vs traditional wheels
✔ Aftermarket direct fit – replaces OEM wheels (Freightliner, Kenworth, Volvo)
✔ Pre-balanced & TPMS-ready – minimizes vibration for smoother rides
✔ Triple-layer protection –surface coating
